| Type | Series | Action | Bore size (mm) |
|---|---|---|---|
| Standard | MGZ | Double acting, Single rod | 20，25，32，40，50，63，80 |
| With end lock | MGZ | Double acting, Single rod | 40，50，63 |
| Without non-rotating mechanism |
MGZR | Double acting, Single rod | 20，25，32，40，50，63，80 |
| Specifications |
MGPK | |||||||
|---|---|---|---|---|---|---|---|---|
| Bore size [mm] |
20 | 25 | 32 | 40 | 50 | 63 | 80 | |
| Action |
Double acting, Single rod |
|||||||
| Fluid |
Air | |||||||
| Proof pressure |
1.5 MPa | |||||||
| Maximum operating pressure |
1.0 MPa | |||||||
| Minimum operating pressure |
Standard stroke: 0.08 MPa | |||||||
| Long stroke: 0.12 MPa |
||||||||
| Ambient and fluid temperature |
Without auto switch: –10° to 70°C (With no freezing) | |||||||
| With auto switch: –10° to 60°C (With no freezing) | ||||||||
| Lubrication |
Not required (Non-lube) | |||||||
| Piston speed |
OUT |
50 to 700 mm/s |
||||||
| IN |
50 to 350 mm/s | 50 to 450 mm/s | ||||||
| Stroke length tolerance | Up to 250: +1.0mm, 251 to 1000: +1.4mm | |||||||
| Cushion |
Rubber bumper | |||||||
| Mounting |
Basic type, Transaxial foot type, Rod flange type, Head flange type | |||||||
