Features

Structure

Driver Controller for Single-Axis Use TLC or THC

Fully Enclosed Design

Strip seals on the side cover and upper surface using magnetic attraction method provide a fully enclosed structure. It prevents any problems caused by entering of foreign materials from outside. As well, the top surface of the strip seal is less likely to generate dust by avoiding the contact.

Fieldbus Compatible Network Unit for Multi-Axis Connections TNU or TJU

Choose Function Mode

Choose the step data count for the TLC and THC depending on your application. You can choose from six function modes: 0, 1, 2, 3 (64-position mode, external input teaching mode, 256-position mode, 512-position mode), 4, and 5 (solenoid modes 1 and 2).

Multi-point Positioning Type

Step data count: Maximum 512 items (varies by function mode) This is optimal for when multiple positioning points are needed.

Electromagnetic Valve Type

Step data count: Maximum 7 items (varies by function mode). Can be used like a cylinder.

Simple Adjustment with the Auto Tuning Function

The auto tuning function simply executes gain adjustments when overshooting occurs due to vibration, abnormal noises, or unstable positioning complete signals during operation.

Simple Setup and Simple Teaching

You can utilize a wealth of features simply by using the PC Setup Tool D-STEP or the Digital Operator TDO.

*The PC Setup Tool D-STEP can be downloaded after creating a free account or logging into THK Online Services.

Functions

• Confirming and editing step data
• Actuator operation (homing, jogging, program execution)
• Monitor (I/O, current position, position commands)
• Alarms (history, alarm reset)

Supports Field Networks Up to a Maximum of 16 Connected Axes

Connecting to the PLC with a fieldbus network enables reduced wiring. Use one TNU (network unit) and up to three TJU (junction unit) together to achieve mixed connections with the THK Driver Controller for up to 16 axes.
