Technical Information

Model M10
Max. object size (L x W x H) (weight) 120 mm (4.724 in) x 80 mm (3.150 in) (1 kg - 2.2 lbs)
Dimensions (L x W x H) 225 mm (8.858 in) x 255 mm (10.039 in) x 290 mm (11.417 in)
Machine weight 7.4 kg (16.314 lb)
Automatic Z axis Yes
Noise level <63 dB
Operating Temperature min. +5°C (+ 41°F) - max. +40°C (+104 °F)
Connection to computer USB / Bluetooth (option)
Maximum speed 25 mm/s (0,98 in/s)
Z stroke (Z travel) 20mm (0.787 in)
Software ABC / Gravostyle / Gravotouch
Tool diameter 3,17 mm (0,12 in)
