Technical Information

Item Specifications
Power Supply 24VDC/10A
Communication Interface 1xLAN (Ethernet TCP/IP), 1xCOM, 1xDB25, (14xDigital Input, 8xDigital Output, IO NPN isolated type)
Vibration (Frequency, Stroke) Frequency range: 10~100Hz, Stroke: 0.1~5mm
Platform size 190 x 232 mm
Workpiece size 2~50 mm
Program Capacity 32
Library / Software .Net Framework (API)
Support robot types Scara robot, 4-axis/6-axis robot ad other robot types
Weight 8.5 kg

Overal Dimension

WxDxH (mm)

222 x 342 x 136.5 (mm)
Options
Backlight Integrated RGB color LED (Red/Green/Blue/White)
Vibration plates Flat, Hole, Grooves, Nets, Various materials
Hopper Various hopper size, support max. 2 hoppers
