| Series | Power Supply Voltage [VAC] |
Upper Level: Frame Size [mm] /Lower Level: Output Power [W] |
|||
| 83 | 91.5 | 91.5 | 105.5 | ||
| 25 | 40 | 60 | 90 | ||
| FPW | Single-Phase 110/115 | ● | ● | ● | ● |
| Single-Phase 220/230 | |||||
| Three-Phase 200/220/230 | |||||
| Product Name | Voltage | Speed | Permissible Torque | Frame Size | Gear Ratio | Output |
|---|---|---|---|---|---|---|
| FPW425A2-100U | Single-Phase 110/115VAC | 18r/min | 8N･m | 83 | 100 | 25W |
| FPW425A2-12.5U | Single-Phase 110/115VAC | 144r/min | 1.7N･m | 83 | 12.5 | 25W |
| FPW425A2-120U | Single-Phase 110/115VAC | 15r/min | 8N･m | 83 | 120 | 25W |
| FPW425A2-150U | Single-Phase 110/115VAC | 12r/min | 8N･m | 83 | 150 | 25W |
| FPW425A2-15U | Single-Phase 110/115VAC | 120r/min | 2.1N･m | 83 | 15 | 25W |
| FPW425A2-180U | Single-Phase 110/115VAC | 10r/min | 8N･m | 83 | 180 | 25W |
| FPW425A2-18U | Single-Phase 110/115VAC | 100r/min | 2.5N･m | 83 | 18 | 25W |
| FPW425A2-25U | Single-Phase 110/115VAC | 72r/min | 3.1N･m | 83 | 25 | 25W |
| FPW425A2-3.6U | Single-Phase 110/115VAC | 500r/min | 0.5N･m | 83 | 3.6 | 25W |
| FPW425A2-30U | Single-Phase 110/115VAC | 60r/min | 3.7N･m | 83 | 30 | 25W |
| FPW425A2-36U | Single-Phase 110/115VAC | 50r/min | 4.5N･m | 83 | 36 | 25W |
| FPW425A2-3U | Single-Phase 110/115VAC | 600r/min | 0.41N･m | 83 | 3 | 25W |
| FPW425A2-50U | Single-Phase 110/115VAC | 36r/min | 5.6N･m | 83 | 50 | 25W |
| FPW425A2-5U | Single-Phase 110/115VAC | 360r/min | 0.69N･m | 83 | 5 | 25W |
| FPW425A2-60U | Single-Phase 110/115VAC | 30r/min | 6.7N･m | 83 | 60 | 25W |
| FPW425A2-6U | Single-Phase 110/115VAC | 300r/min | 0.83N･m | 83 | 6 | 25W |
| FPW425A2-7.5U | Single-Phase 110/115VAC | 240r/min | 1N･m | 83 | 7.5 | 25W |
| FPW425A2-75U | Single-Phase 110/115VAC | 24r/min | 8N･m | 83 | 75 | 25W |
| FPW425A2-90U | Single-Phase 110/115VAC | 20r/min | 8N･m | 83 | 90 | 25W |
| FPW425A2-9U | Single-Phase 110/115VAC | 200r/min | 1.2N･m | 83 | 9 | 25W |
| FPW425C2-100E | Single-Phase 220/230VAC | 15r/min (50Hz) | 8N･m （50Hz） | 83 | 100 | 25W |
| FPW425C2-12.5E | Single-Phase 220/230VAC | 120r/min (50Hz) | 2.1N･m （50Hz） | 83 | 12.5 | 25W |
| FPW425C2-120E | Single-Phase 220/230VAC | 12.5r/min (50Hz) | 8N･m （50Hz） | 83 | 120 | 25W |
| FPW425C2-150E | Single-Phase 220/230VAC | 10r/min (50Hz) | 8N･m （50Hz） | 83 | 150 | 25W |
| FPW425C2-15E | Single-Phase 220/230VAC | 100r/min (50Hz) | 2.5N･m （50Hz） | 83 | 15 | 25W |
| FPW425C2-180E | Single-Phase 220/230VAC | 8.3r/min (50Hz) | 8N･m （50Hz） | 83 | 180 | 25W |
| FPW425C2-18E | Single-Phase 220/230VAC | 83r/min (50Hz) | 3N･m （50Hz） | 83 | 18 | 25W |
| FPW425C2-25E | Single-Phase 220/230VAC | 60r/min (50Hz) | 3.7N･m （50Hz） | 83 | 25 | 25W |
| FPW425C2-3.6E | Single-Phase 220/230VAC | 417r/min (50Hz) | 0.6N･m （50Hz） | 83 | 3.6 | 25W |
| FPW425C2-30E | Single-Phase 220/230VAC | 50r/min (50Hz) | 4.5N･m （50Hz） | 83 | 30 | 25W |
| FPW425C2-36E | Single-Phase 220/230VAC | 42r/min (50Hz) | 5.4N･m （50Hz） | 83 | 36 | 25W |
| FPW425C2-3E | Single-Phase 220/230VAC | 500r/min (50Hz) | 0.5N･m （50Hz） | 83 | 3 | 25W |
| FPW425C2-50E | Single-Phase 220/230VAC | 30r/min (50Hz) | 6.8N･m （50Hz） | 83 | 50 | 25W |
| FPW425C2-5E | Single-Phase 220/230VAC | 300r/min (50Hz) | 0.83N･m （50Hz） | 83 | 5 | 25W |
| FPW425C2-60E | Single-Phase 220/230VAC | 25r/min (50Hz) | 8N･m （50Hz） | 83 | 60 | 25W |
| FPW425C2-6E | Single-Phase 220/230VAC | 250r/min (50Hz) | 1N･m （50Hz） | 83 | 6 | 25W |
| FPW425C2-7.5E | Single-Phase 220/230VAC | 200r/min (50Hz) | 1.2N･m （50Hz） | 83 | 7.5 | 25W |
| FPW425C2-75E | Single-Phase 220/230VAC | 20r/min (50Hz) | 8N･m （50Hz） | 83 | 75 | 25W |
| FPW425C2-90E | Single-Phase 220/230VAC | 17r/min (50Hz) | 8N･m （50Hz） | 83 | 90 | 25W |
| FPW425C2-9E | Single-Phase 220/230VAC | 167r/min (50Hz) | 1.5N･m （50Hz） | 83 | 9 | 25W |
| FPW425S2-100 | Three-Phase 200/220/230VAC | 15r/min (50Hz) | 8N･m （50Hz） | 83 | 100 | 25W |
| FPW425S2-12.5 | Three-Phase 200/220/230VAC | 120r/min (50Hz) | 1.9N･m （50Hz） | 83 | 12.5 | 25W |
| FPW425S2-120 | Three-Phase 200/220/230VAC | 12.5r/min (50Hz) | 8N･m （50Hz） | 83 | 120 | 25W |
| FPW425S2-15 | Three-Phase 200/220/230VAC | 100r/min (50Hz) | 2.3N･m （50Hz） | 83 | 15 | 25W |
| FPW425S2-150 | Three-Phase 200/220/230VAC | 10r/min (50Hz) | 8N･m （50Hz） | 83 | 150 | 25W |
| FPW425S2-18 | Three-Phase 200/220/230VAC | 83r/min (50Hz) | 2.8N･m （50Hz） | 83 | 18 | 25W |
| FPW425S2-180 | Three-Phase 200/220/230VAC | 8.3r/min (50Hz) | 8N･m （50Hz） | 83 | 180 | 25W |
| FPW425S2-25 | Three-Phase 200/220/230VAC | 60r/min (50Hz) | 3.5N･m （50Hz） | 83 | 25 | 25W |
| FPW425S2-3 | Three-Phase 200/220/230VAC | 500r/min (50Hz) | 0.46N･m （50Hz） | 83 | 3 | 25W |
| FPW425S2-3.6 | Three-Phase 200/220/230VAC | 417r/min (50Hz) | 0.55N･m （50Hz） | 83 | 3.6 | 25W |
| FPW425S2-30 | Three-Phase 200/220/230VAC | 50r/min (50Hz) | 4.2N･m （50Hz） | 83 | 30 | 25W |
| FPW425S2-36 | Three-Phase 200/220/230VAC | 42r/min (50Hz) | 5N･m （50Hz） | 83 | 36 | 25W |
| FPW425S2-5 | Three-Phase 200/220/230VAC | 300r/min (50Hz) | 0.77N･m （50Hz） | 83 | 5 | 25W |
| FPW425S2-50 | Three-Phase 200/220/230VAC | 30r/min (50Hz) | 6.3N･m （50Hz） | 83 | 50 | 25W |
| FPW425S2-6 | Three-Phase 200/220/230VAC | 250r/min (50Hz) | 0.92N･m （50Hz） | 83 | 6 | 25W |
| FPW425S2-60 | Three-Phase 200/220/230VAC | 25r/min (50Hz) | 7.5N･m （50Hz） | 83 | 60 | 25W |
| FPW425S2-7.5 | Three-Phase 200/220/230VAC | 200r/min (50Hz) | 1.2N･m （50Hz） | 83 | 7.5 | 25W |
| FPW425S2-75 | Three-Phase 200/220/230VAC | 20r/min (50Hz) | 8N･m （50Hz） | 83 | 75 | 25W |
| FPW425S2-9 | Three-Phase 200/220/230VAC | 167r/min (50Hz) | 1.4N･m （50Hz） | 83 | 9 | 25W |
| FPW425S2-90 | Three-Phase 200/220/230VAC | 17r/min (50Hz) | 8N･m （50Hz） | 83 | 90 | 25W |
| FPW540A2-100U | Single-Phase 110/115VAC | 18r/min | 10N･m | 91.5 | 100 | 40W |
| FPW540A2-12.5U | Single-Phase 110/115VAC | 144r/min | 2.6N･m | 91.5 | 12.5 | 40W |
| FPW540A2-120U | Single-Phase 110/115VAC | 15r/min | 10N･m | 91.5 | 120 | 40W |
| FPW540A2-150U | Single-Phase 110/115VAC | 12r/min | 10N･m | 91.5 | 150 | 40W |
| FPW540A2-15U | Single-Phase 110/115VAC | 120r/min | 3.2N･m | 91.5 | 15 | 40W |
| FPW540A2-180U | Single-Phase 110/115VAC | 10r/min | 10N･m | 91.5 | 180 | 40W |
| FPW540A2-18U | Single-Phase 110/115VAC | 100r/min | 3.8N･m | 91.5 | 18 | 40W |
| FPW540A2-25U | Single-Phase 110/115VAC | 72r/min | 4.7N･m | 91.5 | 25 | 40W |
| FPW540A2-3.6U | Single-Phase 110/115VAC | 500r/min | 0.76N･m | 91.5 | 3.6 | 40W |
| FPW540A2-30U | Single-Phase 110/115VAC | 60r/min | 5.7N･m | 91.5 | 30 | 40W |
| FPW540A2-36U | Single-Phase 110/115VAC | 50r/min | 6.8N･m | 91.5 | 36 | 40W |
| FPW540A2-3U | Single-Phase 110/115VAC | 600r/min | 0.63N･m | 91.5 | 3 | 40W |
| FPW540A2-50U | Single-Phase 110/115VAC | 36r/min | 8.6N･m | 91.5 | 50 | 40W |
| FPW540A2-5U | Single-Phase 110/115VAC | 360r/min | 1.1N･m | 91.5 | 5 | 40W |
| FPW540A2-60U | Single-Phase 110/115VAC | 30r/min | 10N･m | 91.5 | 60 | 40W |
| FPW540A2-6U | Single-Phase 110/115VAC | 300r/min | 1.3N･m | 91.5 | 6 | 40W |
| FPW540A2-7.5U | Single-Phase 110/115VAC | 240r/min | 1.6N･m | 91.5 | 7.5 | 40W |
| FPW540A2-75U | Single-Phase 110/115VAC | 24r/min | 10N･m | 91.5 | 75 | 40W |
| FPW540A2-90U | Single-Phase 110/115VAC | 20r/min | 10N･m | 91.5 | 90 | 40W |
| FPW540A2-9U | Single-Phase 110/115VAC | 200r/min | 1.9N･m | 91.5 | 9 | 40W |
| FPW540C2-100E | Single-Phase 220/230VAC | 15r/min (50Hz) | 10N･m （50Hz） | 91.5 | 100 | 40W |
| FPW540C2-12.5E | Single-Phase 220/230VAC | 120r/min (50Hz) | 3N･m （50Hz） | 91.5 | 12.5 | 40W |
| FPW540C2-120E | Single-Phase 220/230VAC | 12.5r/min (50Hz) | 10N･m （50Hz） | 91.5 | 120 | 40W |
| FPW540C2-150E | Single-Phase 220/230VAC | 10r/min (50Hz) | 10N･m （50Hz） | 91.5 | 150 | 40W |
| FPW540C2-15E | Single-Phase 220/230VAC | 100r/min (50Hz) | 3.6N･m （50Hz） | 91.5 | 15 | 40W |
| FPW540C2-180E | Single-Phase 220/230VAC | 8.3r/min (50Hz) | 10N･m （50Hz） | 91.5 | 180 | 40W |
| FPW540C2-18E | Single-Phase 220/230VAC | 83r/min (50Hz) | 4.4N･m （50Hz） | 91.5 | 18 | 40W |
| FPW540C2-25E | Single-Phase 220/230VAC | 60r/min (50Hz) | 5.5N･m （50Hz） | 91.5 | 25 | 40W |
| FPW540C2-3.6E | Single-Phase 220/230VAC | 417r/min (50Hz) | 0.87N･m （50Hz） | 91.5 | 3.6 | 40W |
| FPW540C2-30E | Single-Phase 220/230VAC | 50r/min (50Hz) | 6.6N･m （50Hz） | 91.5 | 30 | 40W |
| FPW540C2-36E | Single-Phase 220/230VAC | 42r/min (50Hz) | 7.9N･m （50Hz） | 91.5 | 36 | 40W |
| FPW540C2-3E | Single-Phase 220/230VAC | 500r/min (50Hz) | 0.73N･m （50Hz） | 91.5 | 3 | 40W |
| FPW540C2-50E | Single-Phase 220/230VAC | 30r/min (50Hz) | 9.9N･m （50Hz） | 91.5 | 50 | 40W |
| FPW540C2-5E | Single-Phase 220/230VAC | 300r/min (50Hz) | 1.2N･m （50Hz） | 91.5 | 5 | 40W |
| FPW540C2-60E | Single-Phase 220/230VAC | 25r/min (50Hz) | 10N･m （50Hz） | 91.5 | 60 | 40W |
| FPW540C2-6E | Single-Phase 220/230VAC | 250r/min (50Hz) | 1.5N･m （50Hz） | 91.5 | 6 | 40W |
| FPW540C2-7.5E | Single-Phase 220/230VAC | 200r/min (50Hz) | 1.8N･m （50Hz） | 91.5 | 7.5 | 40W |
| FPW540C2-75E | Single-Phase 220/230VAC | 20r/min (50Hz) | 10N･m （50Hz） | 91.5 | 75 | 40W |
| FPW540C2-90E | Single-Phase 220/230VAC | 17r/min (50Hz) | 10N･m （50Hz） | 91.5 | 90 | 40W |
| FPW540C2-9E | Single-Phase 220/230VAC | 167r/min (50Hz) | 2.2N･m （50Hz） | 91.5 | 9 | 40W |
| FPW540S2-100 | Three-Phase 200/220/230VAC | 15r/min (50Hz) | 10N･m （50Hz） | 91.5 | 100 | 40W |
| FPW540S2-12.5 | Three-Phase 200/220/230VAC | 120r/min (50Hz) | 3N･m （50Hz） | 91.5 | 12.5 | 40W |
| FPW540S2-120 | Three-Phase 200/220/230VAC | 12.5r/min (50Hz) | 10N･m （50Hz） | 91.5 | 120 | 40W |
| FPW540S2-15 | Three-Phase 200/220/230VAC | 100r/min (50Hz) | 3.6N･m （50Hz） | 91.5 | 15 | 40W |
| FPW540S2-150 | Three-Phase 200/220/230VAC | 10r/min (50Hz) | 10N･m （50Hz） | 91.5 | 150 | 40W |
| FPW540S2-18 | Three-Phase 200/220/230VAC | 83r/min (50Hz) | 4.4N･m （50Hz） | 91.5 | 18 | 40W |
| FPW540S2-180 | Three-Phase 200/220/230VAC | 8.3r/min (50Hz) | 10N･m （50Hz） | 91.5 | 180 | 40W |
| FPW540S2-25 | Three-Phase 200/220/230VAC | 60r/min (50Hz) | 5.5N･m （50Hz） | 91.5 | 25 | 40W |
| FPW540S2-3 | Three-Phase 200/220/230VAC | 500r/min (50Hz) | 0.73N･m （50Hz） | 91.5 | 3 | 40W |
| FPW540S2-3.6 | Three-Phase 200/220/230VAC | 417r/min (50Hz) | 0.87N･m （50Hz） | 91.5 | 3.6 | 40W |
| FPW540S2-30 | Three-Phase 200/220/230VAC | 50r/min (50Hz) | 6.6N･m （50Hz） | 91.5 | 30 | 40W |
| FPW540S2-36 | Three-Phase 200/220/230VAC | 42r/min (50Hz) | 7.9N･m （50Hz） | 91.5 | 36 | 40W |
| FPW540S2-5 | Three-Phase 200/220/230VAC | 300r/min (50Hz) | 1.2N･m （50Hz） | 91.5 | 5 | 40W |
| FPW540S2-50 | Three-Phase 200/220/230VAC | 30r/min (50Hz) | 9.9N･m （50Hz） | 91.5 | 50 | 40W |
| FPW540S2-6 | Three-Phase 200/220/230VAC | 250r/min (50Hz) | 1.5N･m （50Hz） | 91.5 | 6 | 40W |
| FPW540S2-60 | Three-Phase 200/220/230VAC | 25r/min (50Hz) | 10N･m （50Hz） | 91.5 | 60 | 40W |
| FPW540S2-7.5 | Three-Phase 200/220/230VAC | 200r/min (50Hz) | 1.8N･m （50Hz） | 91.5 | 7.5 | 40W |
| FPW540S2-75 | Three-Phase 200/220/230VAC | 20r/min (50Hz) | 10N･m （50Hz） | 91.5 | 75 | 40W |
| FPW540S2-9 | Three-Phase 200/220/230VAC | 167r/min (50Hz) | 2.2N･m （50Hz） | 91.5 | 9 | 40W |
| FPW540S2-90 | Three-Phase 200/220/230VAC | 17r/min (50Hz) | 10N･m （50Hz） | 91.5 | 90 | 40W |
| FPW560A2-100U | Single-Phase 110/115VAC | 18r/min | 15N･m | 91.5 | 100 | 60W |
| FPW560A2-12.5U | Single-Phase 110/115VAC | 144r/min | 3.7N･m | 91.5 | 12.5 | 60W |
| FPW560A2-120U | Single-Phase 110/115VAC | 15r/min | 15N･m | 91.5 | 120 | 60W |
| FPW560A2-150U | Single-Phase 110/115VAC | 12r/min | 15N･m | 91.5 | 150 | 60W |
| FPW560A2-15U | Single-Phase 110/115VAC | 120r/min | 4.4N･m | 91.5 | 15 | 60W |
| FPW560A2-180U | Single-Phase 110/115VAC | 10r/min | 15N･m | 91.5 | 180 | 60W |
| FPW560A2-18U | Single-Phase 110/115VAC | 100r/min | 5.3N･m | 91.5 | 18 | 60W |
| FPW560A2-25U | Single-Phase 110/115VAC | 72r/min | 6.7N･m | 91.5 | 25 | 60W |
| FPW560A2-3.6U | Single-Phase 110/115VAC | 500r/min | 1.2N･m | 91.5 | 3.6 | 60W |
| FPW560A2-30U | Single-Phase 110/115VAC | 60r/min | 8N･m | 91.5 | 30 | 60W |
| FPW560A2-36U | Single-Phase 110/115VAC | 50r/min | 9.6N･m | 91.5 | 36 | 60W |
| FPW560A2-3U | Single-Phase 110/115VAC | 600r/min | 0.98N･m | 91.5 | 3 | 60W |
| FPW560A2-50U | Single-Phase 110/115VAC | 36r/min | 13.4N･m | 91.5 | 50 | 60W |
| FPW560A2-5U | Single-Phase 110/115VAC | 360r/min | 1.6N･m | 91.5 | 5 | 60W |
| FPW560A2-60U | Single-Phase 110/115VAC | 30r/min | 15N･m | 91.5 | 60 | 60W |
| FPW560A2-6U | Single-Phase 110/115VAC | 300r/min | 2N･m | 91.5 | 6 | 60W |
| FPW560A2-7.5U | Single-Phase 110/115VAC | 240r/min | 2.5N･m | 91.5 | 7.5 | 60W |
| FPW560A2-75U | Single-Phase 110/115VAC | 24r/min | 15N･m | 91.5 | 75 | 60W |
| FPW560A2-90U | Single-Phase 110/115VAC | 20r/min | 15N･m | 91.5 | 90 | 60W |
| FPW560A2-9U | Single-Phase 110/115VAC | 200r/min | 3N･m | 91.5 | 9 | 60W |
| FPW560C2-100E | Single-Phase 220/230VAC | 15r/min (50Hz) | 15N･m （50Hz） | 91.5 | 100 | 60W |
| FPW560C2-12.5E | Single-Phase 220/230VAC | 120r/min (50Hz) | 3.9N･m （50Hz） | 91.5 | 12.5 | 60W |
| FPW560C2-120E | Single-Phase 220/230VAC | 12.5r/min (50Hz) | 15N･m （50Hz） | 91.5 | 120 | 60W |
| FPW560C2-150E | Single-Phase 220/230VAC | 10r/min (50Hz) | 15N･m （50Hz） | 91.5 | 150 | 60W |
| FPW560C2-15E | Single-Phase 220/230VAC | 100r/min (50Hz) | 4.7N･m （50Hz） | 91.5 | 15 | 60W |
| FPW560C2-180E | Single-Phase 220/230VAC | 8.3r/min (50Hz) | 15N･m （50Hz） | 91.5 | 180 | 60W |
| FPW560C2-18E | Single-Phase 220/230VAC | 83r/min (50Hz) | 5.7N･m （50Hz） | 91.5 | 18 | 60W |
| FPW560C2-25E | Single-Phase 220/230VAC | 60r/min (50Hz) | 7.1N･m （50Hz） | 91.5 | 25 | 60W |
| FPW560C2-3.6E | Single-Phase 220/230VAC | 417r/min (50Hz) | 1.3N･m （50Hz） | 91.5 | 3.6 | 60W |
| FPW560C2-30E | Single-Phase 220/230VAC | 50r/min (50Hz) | 8.5N･m （50Hz） | 91.5 | 30 | 60W |
| FPW560C2-36E | Single-Phase 220/230VAC | 42r/min (50Hz) | 10.2N･m （50Hz） | 91.5 | 36 | 60W |
| FPW560C2-3E | Single-Phase 220/230VAC | 500r/min (50Hz) | 1N･m （50Hz） | 91.5 | 3 | 60W |
| FPW560C2-50E | Single-Phase 220/230VAC | 30r/min (50Hz) | 14.2N･m （50Hz） | 91.5 | 50 | 60W |
| FPW560C2-5E | Single-Phase 220/230VAC | 300r/min (50Hz) | 1.7N･m （50Hz） | 91.5 | 5 | 60W |
| FPW560C2-60E | Single-Phase 220/230VAC | 25r/min (50Hz) | 15N･m （50Hz） | 91.5 | 60 | 60W |
| FPW560C2-6E | Single-Phase 220/230VAC | 250r/min (50Hz) | 2.1N･m （50Hz） | 91.5 | 6 | 60W |
| FPW560C2-7.5E | Single-Phase 220/230VAC | 200r/min (50Hz) | 2.6N･m （50Hz） | 91.5 | 7.5 | 60W |
| FPW560C2-75E | Single-Phase 220/230VAC | 20r/min (50Hz) | 15N･m （50Hz） | 91.5 | 75 | 60W |
| FPW560C2-90E | Single-Phase 220/230VAC | 17r/min (50Hz) | 15N･m （50Hz） | 91.5 | 90 | 60W |
| FPW560C2-9E | Single-Phase 220/230VAC | 167r/min (50Hz) | 3.1N･m （50Hz） | 91.5 | 9 | 60W |
| FPW560S2-100 | Three-Phase 200/220/230VAC | 15r/min (50Hz) | 15N･m （50Hz） | 91.5 | 100 | 60W |
| FPW560S2-12.5 | Three-Phase 200/220/230VAC | 120r/min (50Hz) | 4.1N･m （50Hz） | 91.5 | 12.5 | 60W |
| FPW560S2-120 | Three-Phase 200/220/230VAC | 12.5r/min (50Hz) | 15N･m （50Hz） | 91.5 | 120 | 60W |
| FPW560S2-15 | Three-Phase 200/220/230VAC | 100r/min (50Hz) | 4.9N･m （50Hz） | 91.5 | 15 | 60W |
| FPW560S2-150 | Three-Phase 200/220/230VAC | 10r/min (50Hz) | 15N･m （50Hz） | 91.5 | 150 | 60W |
| FPW560S2-18 | Three-Phase 200/220/230VAC | 83r/min (50Hz) | 5.9N･m （50Hz） | 91.5 | 18 | 60W |
| FPW560S2-180 | Three-Phase 200/220/230VAC | 8.3r/min (50Hz) | 15N･m （50Hz） | 91.5 | 180 | 60W |
| FPW560S2-25 | Three-Phase 200/220/230VAC | 60r/min (50Hz) | 7.4N･m （50Hz） | 91.5 | 25 | 60W |
| FPW560S2-3 | Three-Phase 200/220/230VAC | 500r/min (50Hz) | 1.1N･m （50Hz） | 91.5 | 3 | 60W |
| FPW560S2-3.6 | Three-Phase 200/220/230VAC | 417r/min (50Hz) | 1.3N･m （50Hz） | 91.5 | 3.6 | 60W |
| FPW560S2-30 | Three-Phase 200/220/230VAC | 50r/min (50Hz) | 8.9N･m （50Hz） | 91.5 | 30 | 60W |
| FPW560S2-36 | Three-Phase 200/220/230VAC | 42r/min (50Hz) | 10.7N･m （50Hz） | 91.5 | 36 | 60W |
| FPW560S2-5 | Three-Phase 200/220/230VAC | 300r/min (50Hz) | 1.8N･m （50Hz） | 91.5 | 5 | 60W |
| FPW560S2-50 | Three-Phase 200/220/230VAC | 30r/min (50Hz) | 14.9N･m （50Hz） | 91.5 | 50 | 60W |
| FPW560S2-6 | Three-Phase 200/220/230VAC | 250r/min (50Hz) | 2.2N･m （50Hz） | 91.5 | 6 | 60W |
| FPW560S2-60 | Three-Phase 200/220/230VAC | 25r/min (50Hz) | 15N･m （50Hz） | 91.5 | 60 | 60W |
| FPW560S2-7.5 | Three-Phase 200/220/230VAC | 200r/min (50Hz) | 2.7N･m （50Hz） | 91.5 | 7.5 | 60W |
| FPW560S2-75 | Three-Phase 200/220/230VAC | 20r/min (50Hz) | 15N･m （50Hz） | 91.5 | 75 | 60W |
| FPW560S2-9 | Three-Phase 200/220/230VAC | 167r/min (50Hz) | 3.3N･m （50Hz） | 91.5 | 9 | 60W |
| FPW560S2-90 | Three-Phase 200/220/230VAC | 17r/min (50Hz) | 15N･m （50Hz） | 91.5 | 90 | 60W |
| FPW690A2-100U | Single-Phase 110/115VAC | 18r/min | 30N･m | 106.5 | 100 | 90W |
| FPW690A2-12.5U | Single-Phase 110/115VAC | 144r/min | 5.3N･m | 106.5 | 12.5 | 90W |
| FPW690A2-120U | Single-Phase 110/115VAC | 15r/min | 30N･m | 106.5 | 120 | 90W |
| FPW690A2-150U | Single-Phase 110/115VAC | 12r/min | 30N･m | 106.5 | 150 | 90W |
| FPW690A2-15U | Single-Phase 110/115VAC | 120r/min | 6.4N･m | 106.5 | 15 | 90W |
| FPW690A2-180U | Single-Phase 110/115VAC | 10r/min | 30N･m | 106.5 | 180 | 90W |
| FPW690A2-18U | Single-Phase 110/115VAC | 100r/min | 7.7N･m | 106.5 | 18 | 90W |
| FPW690A2-25U | Single-Phase 110/115VAC | 72r/min | 10.7N･m | 106.5 | 25 | 90W |
| FPW690A2-3.6U | Single-Phase 110/115VAC | 500r/min | 1.7N･m | 106.5 | 3.6 | 90W |
| FPW690A2-30U | Single-Phase 110/115VAC | 60r/min | 12.8N･m | 106.5 | 30 | 90W |
| FPW690A2-36U | Single-Phase 110/115VAC | 50r/min | 15.4N･m | 106.5 | 36 | 90W |
| FPW690A2-3U | Single-Phase 110/115VAC | 600r/min | 1.4N･m | 106.5 | 3 | 90W |
| FPW690A2-50U | Single-Phase 110/115VAC | 36r/min | 19.3N･m | 106.5 | 50 | 90W |
| FPW690A2-5U | Single-Phase 110/115VAC | 360r/min | 2.4N･m | 106.5 | 5 | 90W |
| FPW690A2-60U | Single-Phase 110/115VAC | 30r/min | 23.2N･m | 106.5 | 60 | 90W |
| FPW690A2-6U | Single-Phase 110/115VAC | 300r/min | 2.8N･m | 106.5 | 6 | 90W |
| FPW690A2-7.5U | Single-Phase 110/115VAC | 240r/min | 3.6N･m | 106.5 | 7.5 | 90W |
| FPW690A2-75U | Single-Phase 110/115VAC | 24r/min | 29N･m | 106.5 | 75 | 90W |
| FPW690A2-90U | Single-Phase 110/115VAC | 20r/min | 30N･m | 106.5 | 90 | 90W |
| FPW690A2-9U | Single-Phase 110/115VAC | 200r/min | 4.3N･m | 106.5 | 9 | 90W |
| FPW690C2-100E | Single-Phase 220/230VAC | 15r/min (50Hz) | 30N･m （50Hz） | 106.5 | 100 | 90W |
| FPW690C2-12.5E | Single-Phase 220/230VAC | 120r/min (50Hz) | 6.4N･m （50Hz） | 106.5 | 12.5 | 90W |
| FPW690C2-120E | Single-Phase 220/230VAC | 12.5r/min (50Hz) | 30N･m （50Hz） | 106.5 | 120 | 90W |
| FPW690C2-150E | Single-Phase 220/230VAC | 10r/min (50Hz) | 30N･m （50Hz） | 106.5 | 150 | 90W |
| FPW690C2-15E | Single-Phase 220/230VAC | 100r/min (50Hz) | 7.7N･m （50Hz） | 106.5 | 15 | 90W |
| FPW690C2-180E | Single-Phase 220/230VAC | 8.3r/min (50Hz) | 30N･m （50Hz） | 106.5 | 180 | 90W |
| FPW690C2-18E | Single-Phase 220/230VAC | 83r/min (50Hz) | 9.2N･m （50Hz） | 106.5 | 18 | 90W |
| FPW690C2-25E | Single-Phase 220/230VAC | 60r/min (50Hz) | 12.8N･m （50Hz） | 106.5 | 25 | 90W |
| FPW690C2-3.6E | Single-Phase 220/230VAC | 417r/min (50Hz) | 2N･m （50Hz） | 106.5 | 3.6 | 90W |
| FPW690C2-30E | Single-Phase 220/230VAC | 50r/min (50Hz) | 15.3N･m （50Hz） | 106.5 | 30 | 90W |
| FPW690C2-36E | Single-Phase 220/230VAC | 42r/min (50Hz) | 18.4N･m （50Hz） | 106.5 | 36 | 90W |
| FPW690C2-3E | Single-Phase 220/230VAC | 500r/min (50Hz) | 1.7N･m （50Hz） | 106.5 | 3 | 90W |
| FPW690C2-50E | Single-Phase 220/230VAC | 30r/min (50Hz) | 23.1N･m （50Hz） | 106.5 | 50 | 90W |
| FPW690C2-5E | Single-Phase 220/230VAC | 300r/min (50Hz) | 2.8N･m （50Hz） | 106.5 | 5 | 90W |
| FPW690C2-60E | Single-Phase 220/230VAC | 25r/min (50Hz) | 27.7N･m （50Hz） | 106.5 | 60 | 90W |
| FPW690C2-6E | Single-Phase 220/230VAC | 250r/min (50Hz) | 3.4N･m （50Hz） | 106.5 | 6 | 90W |
| FPW690C2-7.5E | Single-Phase 220/230VAC | 200r/min (50Hz) | 4.3N･m （50Hz） | 106.5 | 7.5 | 90W |
| FPW690C2-75E | Single-Phase 220/230VAC | 20r/min (50Hz) | 30N･m （50Hz） | 106.5 | 75 | 90W |
| FPW690C2-90E | Single-Phase 220/230VAC | 17r/min (50Hz) | 30N･m （50Hz） | 106.5 | 90 | 90W |
| FPW690C2-9E | Single-Phase 220/230VAC | 167r/min (50Hz) | 5.1N･m （50Hz） | 106.5 | 9 | 90W |
| FPW690S2-100 | Three-Phase 200/220/230VAC | 15r/min (50Hz) | 30N･m （50Hz） | 106.5 | 100 | 90W |
| FPW690S2-12.5 | Three-Phase 200/220/230VAC | 120r/min (50Hz) | 6.2N･m （50Hz） | 106.5 | 12.5 | 90W |
| FPW690S2-120 | Three-Phase 200/220/230VAC | 12.5r/min (50Hz) | 30N･m （50Hz） | 106.5 | 120 | 90W |
| FPW690S2-15 | Three-Phase 200/220/230VAC | 100r/min (50Hz) | 7.4N･m （50Hz） | 106.5 | 15 | 90W |
| FPW690S2-150 | Three-Phase 200/220/230VAC | 10r/min (50Hz) | 30N･m （50Hz） | 106.5 | 150 | 90W |
| FPW690S2-18 | Three-Phase 200/220/230VAC | 83r/min (50Hz) | 8.9N･m （50Hz） | 106.5 | 18 | 90W |
| FPW690S2-180 | Three-Phase 200/220/230VAC | 8.3r/min (50Hz) | 30N･m （50Hz） | 106.5 | 180 | 90W |
| FPW690S2-25 | Three-Phase 200/220/230VAC | 60r/min (50Hz) | 12.4N･m （50Hz） | 106.5 | 25 | 90W |
| FPW690S2-3 | Three-Phase 200/220/230VAC | 500r/min (50Hz) | 1.7N･m （50Hz） | 106.5 | 3 | 90W |
| FPW690S2-3.6 | Three-Phase 200/220/230VAC | 417r/min (50Hz) | 2N･m （50Hz） | 106.5 | 3.6 | 90W |
| FPW690S2-30 | Three-Phase 200/220/230VAC | 50r/min (50Hz) | 14.9N･m （50Hz） | 106.5 | 30 | 90W |
| FPW690S2-36 | Three-Phase 200/220/230VAC | 42r/min (50Hz) | 17.9N･m （50Hz） | 106.5 | 36 | 90W |
| FPW690S2-5 | Three-Phase 200/220/230VAC | 300r/min (50Hz) | 2.8N･m （50Hz） | 106.5 | 5 | 90W |
| FPW690S2-50 | Three-Phase 200/220/230VAC | 30r/min (50Hz) | 22.4N･m （50Hz） | 106.5 | 50 | 90W |
| FPW690S2-6 | Three-Phase 200/220/230VAC | 250r/min (50Hz) | 3.3N･m （50Hz） | 106.5 | 6 | 90W |
| FPW690S2-60 | Three-Phase 200/220/230VAC | 25r/min (50Hz) | 26.9N･m （50Hz） | 106.5 | 60 | 90W |
| FPW690S2-7.5 | Three-Phase 200/220/230VAC | 200r/min (50Hz) | 4.1N･m （50Hz） | 106.5 | 7.5 | 90W |
| FPW690S2-75 | Three-Phase 200/220/230VAC | 20r/min (50Hz) | 30N･m （50Hz） | 106.5 | 75 | 90W |
| FPW690S2-9 | Three-Phase 200/220/230VAC | 167r/min (50Hz) | 5N･m （50Hz） | 106.5 | 9 | 90W |
| FPW690S2-90 | Three-Phase 200/220/230VAC | 17r/min (50Hz) | 30N･m （50Hz） | 106.5 | 90 | 90W |
