The ultra-compact and cost-efficient Ensenso S10 works with 60° field of view in a working range of 0.4 - 3 m with high depth accuracy. This makes it very versatile in a wide range of applications.
The 3D cameras meet protection class IP65/67 and are therefore optimally protected against dirt, dust, water splashes or cleaning agents.
The 3D laser point triangulation of Ensenso S10 camera models is accelerated by a neural network. At full projector power, this allows to create up to 20 point clouds per second with consistently high quality and resolution.
| Specifications | Ensenso S10 |
| Measurement Distance | 1147 mm - 1680 mm |
| AOI (x / y / width / height) | 99 / 93 / 1351 / 902 |
| Dimensions | 130 x 45 x 44 mm |
| Weight | 565 g |
| Resolution | 1456 x 1088 (1.6 MP) |
| Frames per Second | 20 |
| Interface | Gigabit Ethernet |
| Input Voltage | 12 V - 24 V DC / PoE |
| Temperature - Operation | 0 - 40 °C |
| Temperature - Storage | 0 - 50 °C |
