Technical Information



Specification GMW L-2E
Lacing Thread Dia. (mm) max Ø1.2
Stator OD/ID Limit (mm)

IDØ40-90

ODØ160 max

Stator Core Length Limit (mm) 20-150
Cycle Time (sec) <0.7 sec/time
Floor Area (W*L*H) (cm)  145*220*220
Machine Weight (Kg) 2600 kg
Main Operation Power Source (KW) 6.5
Max. Power Consumption (KW) 11.3
Pneumatic Source (Kg/cm²) 4-7
Use voltage Can be customized according to the voltage used in each country
