PRECISION NEEDLE VALVE SV51 SAN-EI-TECH

High-precision needle valve for micro-volume dispensing of low-viscosity fluids (as small as 0.001 cc) from San-ei Tech.

Model: SV51

Technical Information

Model SV51
Size φ26.9mm (Fluid body) x 113mm length
Weight 312g (except fluid inlet fitting part)
Tip adapter /Needle sheet SUS303
 Air cylinder body SUS303
Piston needle SUS303
Needle packing SUS303, Teflon®
Fluid inlet thread 1/8NPT female
Valve operating air inlet thread  M5×0.8 female
Mounting M6 tapped hole
Valve operating air pressure 0.4～0.62MPa
Maximum fluid pressure 0.7MPa
