Technical Information



Model JPU-0055 JPU-0105 JPU-0205 JPU-0505 JPU-1005 JPU-2005 JPU-3005 JPU-5005 JPU-8005
Capacity (KN) 0.5 1 2 5 10 20 30 50 80
Stroke (mm) 80 100 200
Max. speed (mm/s) 414 280 320 250
Repeatability (mm) ±0.005mm
Press unit Dimensions WxDxH (mm) 116x218x425 146x258x502 171x384x706 230x474x775 260x477x797
Weight (kg) 17 34 80 161 167 170
Standard controller Dimensions WxDxH (mm) 350x310x163 350x310x209 428x338x175 514x365x283
Weight (kg) 11 12 13 21
Compact controller Dimensions WxDxH (mm) 140x280x292 160x280x287
Weight (kg) 5.8 6.4 7.5 9.0
External Regenerative Resistance Dimensions WxDxH (mm) - 150x46x275 100x318x142 120x199x345
Weight (kg) - 1.1 2.9 5.6
