Technical Information

Model

Tray Width

(mm)

Tray Depth

(mm)

Tray Wall Height

(mm)

Maximum Tray Payload Capacity

(kg)

Unit Footprint Internal Bay

(W x D)

Unit Footprint External Bay

(W x D)

MC25 2.500 654 45/70/120 250 W = 2.917
D = 2.556
W = 2.917
D = 3.246
MC25D 2.500 857 45/70/120 250 W = 2.917
D = 3.165
W = 2.917
D = 4.058
MC50 2.500 654 70/120 500 W = 2.917
D = 2.556
W = 2.917
D = 3.246
MC50D 2.500 857 70/120 500 W = 2.917
D = 3.165
W = 2.917
D = 4.058
MC75 2.500 654 70/120 750 W = 2.917
D = 2.556
W = 2.917
D = 3.246
MC75D 2.500 857 70/120 750 W = 2.917
D = 3.165
W = 2.917
D = 4.058
MC1000 2.460 654 120 990 W = 2.917
D = 2.556
W = 2.917
D = 3.246
MC1000D 2.460 857 120 990 W = 2.917
D = 3.165
W = 2.917
D = 4.058
