Technical Information

  1. Gmwsw-5c Is An In-Slot Winder With Hi-Tech Ipc Control Which Operates Very Precisely, Rapidly Adjustable, Easy Maintenance, High Flexibility.
  2. Gmwsw-5c Is Available For Servomotor, Stepmotor, Induction- Motor, Regency-Motor..& So On.
  3. Operation, Setting & Control: Industrial Pc, Hmi Panel, 3-Axes Servomotor Drive, Fully-Digital Data Setting & Touch Lcd Monitor.Distributing Winding & Tension Unit: Precise Square Winding Route With Accurate Distributing, Automatic Procedure, Magnetic Tension Control & Fully Enclosed Sensor Cap.
  4. Inner-Tooling Layering Design Is Excellent For Winding Wire Alignment Installing, Adjusting And Maintaining.



STATOR INSIDE DIA. 50 – 65 mm
STATOR STACK HEIGHT 8 – 50 mm
NUMBER OF SLOTS 4 – 24Slots
WIRE DIA. 0.14 - 0.6 mm
SPEED 1000rpm(max)
POWER SUPPLY Air Pressure 5-8 BAR,AC 220V/380V, 3 PHASE 50/60HZ
DRIVE MOTOR AC 3KW Servo-Moto
DIMENSION 180(L)*156(W)*180(H)cm
WEIGHT 1250Kgs
