1D & 2D GENERAL PURPOSE HANDHELD BARCODE SCANNER MARS TOHKEN | THIR-6780 SERIES

Model: THIR-6780R, THIR-6780R-H, THIR-6780U, THIR-6780U-H, THIR-6781U, THIR-6781U-ESD, THIR-6781R, THIR-6781R-ESD

Technical Information

Model THIR-6780R(-H)/THIR-6780U(-H) THIR-6781U(-ESD)/ THIR-6781R(-ESD)
Interface RS-232C, USB/HID (controled by function button or via software), Detachable cable
Supported Barcodes (2D) DataMatrix(ECC200), PDF417, MaxiCode, QR Code, MicroQR, MicroPDF, GS1 Data Bar Composite
Supported barcodes (1D)  JAN/EAN/UPC, ITF, Codabar, Code39, Code93, Code128, EAN128, GS1 Data Bar, Customer barcode
(optional)
Minimum resolution Normal type: 1D 0.19mm, 2D 0.25mm
High resolution type: 1D: 0.125mm, 2D 0.167mm 		 1D 0.125mm, 2D 0.167mm
Power and power
consumption		 DC5.0V+/-5%, 400mA @ 5.0V
Operating
temp./humidity		 0 to 40C / 35 to 85%RH (non-condensing)
Storage temp. /humidity  -20 to 65 C / 35 to 85%RH (non-condensing)
Drop specification Multiple drops from 2m to concrete (no reduction in reading performance)
Dimensions 60(W) x 162(H) x 125(D)mm
Weight  159g (without cable)
