Technical Information

Fluid Air
Operating pressure range 0 to 1.0 MPa
Proof pressure 1.5 MPa
Ambient and fluid temperature –5 to 60°C (No freezing)

Flow rate characteristics (With nozzle removed)

C(dm3 /s·bar): 6.0, b: 0.25 (Effective area: 30 mm2)
Port size  Rc, NPT, G 1/4, 3/8
Piping entry  Top
Nozzle port size Rc 1/4
Weight (Main unit only) 165g
Operational force (when
the valve is fully open)
7N
