Technical Information

Fluid Air
Operating pressure range
MPa
2 position single  0.15 to 0.7
2 position double  –100 kPa to 0,7
3 position  –100 kPa to 0,7
Pilot pressure range Note(1) MPa 2 position single   (0.7 x P + 0.1) to 0.7 P: Operating pressure range
2 position double  0,1 to 0,7
3 position  0,2 to 0,7
Ambient and fluid temperature (°C)  –10 to 60 (No freezing.)
Manual override (Manual operation)  Non-locking push type
Lubrication Not required
Mounting orientation  Unrestricted
Impact/Vibration resistance (m/s2) Note 2) 150/30
