SERIAL INTERFACE UNIT SMC EX120

Fieldbus system (For output)

Model: EX120-SDN1/EX123U-SUH1/EX124U-SDN1

Technical Information

Communication Terminating resistor Not provided
Internal current consumption (Unit)  100 mA or less
Environment Protection Level IP20
Operating Temperature 0 to 55°C (8-point valve ON)
0 to 50°C (16-point ON valve)
Humidity Range 35 to 85% RH (No Condensation)
Withstand Voltage 1500 VAC for 1 minute between all external terminals and the enclosure
Electrical resistance material 2 MΩ or more (500 VDC) between all external terminals and the case
