| Model | MCR-F530 |
| Interface | RS-232C, Ethernet (10 Base-T, 100BASE-TX) |
| Supported barcodes (2D) | DataMatrix(ECC200), QR Code, MicroQR, PDF417 |
| Supported barcodes (1D) | JAN / EAN / UPC, ITF, Codabar, Code39, Code93, Code128, EAN128, GS1 Data bar |
| Integrated lighting | White LED |
| Minimum resolution | 0,1mm |
| Power supply |
DC power supply: 24 VDC ± 10% (scanner connector: power input) PoE power supply: Type A / B, DC 36 to 57 V (LAN connector) * Can not be used with DC power supply system |
| Power consumption | DC power supply: command (synchronous) standby: about 150 mA / reading operation: Approx 450 mA |
| Operating temp./humidity | 0 ~ 40 C / 35 ~ 85% RH (non-condensing) |
| Storage temp. /humidity |
-20 to 65 C / 35 ~ 85% RH (non-condensing) |
| Digital input | Photocoupler insulation x 1 point Input resistance: 1 kΩ OFF voltage: 0 to 0.8 V, ON voltage: 6 to 28 V |
| Digital output | Photocoupler insulation x 3 points Maximum rating DC 30 V 50 mA |
| Dimensions | 65(W) x 54(H) x 71(D)mm |
| Weight | 320g |
