Technical Information

Item Description
Power supply voltage 100V to 240V AC (+10% -15%) (free power supply), 50/60 Hz, 12 to 24V DC (±15%) (Please specify when ordering.)
Power consumption 15W max
Operating conditions Temperature: Working temperature range -10 to +40°C;Storage temperature range -40 to +80°CHumidity: 85% RH or less (non-condensing)
Dimensions 96(W)×96(H)×135(D) mm (protruding parts not included)
Panel cutout dimensions 92×92(+1-0)mm
Weight Approx. 0.9kg
CE marking certification EMC directives: EN61326-1Safety standard: EN61010-1, EN62311
