| Model | UNTCH-5KN, UNTCH-10KN, UNTCH-20KN, UNTCH-50KN, UNTCH-100KN | Unit |
| Rated capacity | 5k, 10k, 20k, 50k, 100k | N |
| Rated output | 1±1% | mV/V |
| Safe overload | 120 | %R.C. |
| Zero balance | ±5 | %R.O. |
| Non-linearity | 0.5 | %R.O. |
| Non-linearity | 0.5 | %R.O. |
| Compensated temperature range | -10 to +70 | ℃ |
| Safe temperature range | -30 to +80 | ℃ |
| Temperature effect on zero | 0.1 | %R.O./10℃ |
| Temperature effect on span | 0.1 | %R.O./10℃ |
| Input resistance | Approx.350 | Ω |
| Output resistance | Approx.350 | Ω |
| Recommended excitation voltage | 10 | V |
| Maxmum excitation voltage | 20 | V |
| Insulation resistance (DC50V) | 2000 or more | MΩ |
| Cable | φ6 4-conductor color shield cable. Length 3m. End treatment 5-leads. | m |
| Cable color code | ＋EXC: Red＋SIG: White－EXC: Blue－SIG: BlackSHIELD | |
| Deflection at rated | 5KN：0.02510KN：0.02520KN：0.04550KN：0.050100KN：0.065 | mm |
| Natural frequency | 5KN：1310KN：720KN：1150KN：14100KN：20 | kHz |
| Weight | 5KN：0.310KN：0.9520KN：1.050KN：1.0100KN：1.0 | g |
