| Model | JR3303T | JR3353T | |
| Model type | Dispensing | Standard: Screw Tightening | |
| Operating range | X-L Axis | 300 mm | 300 mm |
| X-R Axis | 300 mm | 300 mm | |
| Y Axis | 320 mm | 510 mm | |
| Z Axis | 50 mm | 100 mm | |
| X Table Size | 128*60 | 156*170 mm | |
| Space between X tables | 180 mm | 303 mm | |
| Maximum portable load | X Axis: 7 kg , Y Axis: 3.5 kg | X Axis: 15 kg, Y Axis: 7 kg | |
| Max Speed | 600 mm/s | 850 mm/s | |
| Repeatability | X-L, X-R, Y: +/-0.007 mm; Z: +/-0.006 mm | X-L, X-R, Z: +/-0.007 mm; Y: +/-0.008 mm | |
| External Dimensions W*D*H (mm) | 560*534*554 | 755*534*678 | |
| Body Weight | 35 kg | 43 kg | |
| Program Capacity | 999 programs | ||
| Database Capacity | 32.000 points | ||
| I/O-SYS | 16 Inputs/ 16 Outputs | ||
| I/O-1 | 8 Inputs/ 8 Outputs (Option) | ||
| COM 1 | RS232C | ||
| COM 2, COM 3 | RS232(Option) | ||
| MEMORY | Save and readout teaching data, upgrade system software | ||
| LAN | Ethernet connector for PC (for robot control via control commands, connecting to "JR C-points II' PC software) | ||
| Language | English, Japanese, Korean, Chinese, Vietnamese... | ||
| Power Supply | AC100-120V/AC200-240V (1 phase) | ||
| Power Capacity | 240W | ||
| Operating Environment Temperature | 0 – 40ºC | ||
| Relative Humidity | 20 -90% | ||
